Feature Konica Minolta Nassenger 10:
- Missprint Recovery : empty nozzle compensation
- Functions ensuring stable production : Equipped with head maintenance functions (printhead cleaning and empty nozzle detection systems)
- Design performance with striking beauty
- Diverse print modes : NASSENGER 10 offers print modes to suit your diverse needs for handling tight deadlines, high precision imaging, and high ink concentration/permeability.
Benefit Konica Minolta Nassenger 10:
High quality ink for flexible color re-creation with 8 color standard (4 base + 2 special + 2 light colors) or 9 colors optional. The Naassenger series greatly reduces environmental burdens compared to convential flat screen textile printers.
Specifications
| Product Name | NASSENGER 10 | ||
| Technology | Drop on-demand piezo inkjet technology | ||
| Printhead | 1024 nozzles water-based inkjet printhead x 8colors72pcs (max. 9colors81pcs) | ||
| Ink | Reactive dye ink TYPE-P | Yellow,ExtraMagenta,Cyan,Black,Orange,Blue,Pink,Gray,Sky | |
| Disperse dye ink TYPE-S | Yellow,Magenta,Cyan,Black,Pink,Sky,Gray,Red,Violet | ||
| Acid dye ink | Yellow,Magenta,Cyan,Black,Blue,Light Magenta,Orange,Light Cyan,Light Black | ||
| Printing Width | 1,850mm | ||
| Maximum Fabric Thickness | 8mm | ||
| Printing Mode | Draft | 370 ～ 990m2/h (with 8 colors) | 360 ～ 980m2/h (with 9 colors) |
| Standard1 | 310 ～ 580m2/h (with 8 colors) | 300 ～ 570m2/h (with 9 colors) | |
| Standard2 | 140 ～ 450m2/h (with 8 colors) | 140 ～ 440m2/h (with 9 colors) | |
| Standard3 | 120 ～ 230m2/h (with 8 colors) | 120 ～ 230m2/h (with 9 colors) | |
| Extra1 | 70 ～ 230m2/h (with 8 colors) | 70 ～ 230m2/h (with 9 colors) | |
| Extra2 | 60 ～ 120m2/h (with 8 colors) | 60 ～ 120m2/h (with 9 colors) | |
| Operating Environment / humidity condition | Mechanical Operating Condition | 15～30℃ 40～70％RH | |
| Color certifing condition of reactive dye ink | 20～28℃ 40～70 ％RH | ||
| Dimensions(W × D × H) | Scan Unit | W 5,800 × D 2,020 × H 1,860 （mm) | |
| Trasport Unit | W 2,600 × D 4,360 × H 1,140 （mm) | ||
| Belt cleaning Unit | W 2,360 × D 783 × H 662 （mm) | ||
| Weight | Scan Unit | Approx. 1,800kg | |
| Trasport Unit | Approx. 2,100kg | ||
| Belt cleaning Unit | Approx. 300kg | ||
| Power supply | AC Single Phase 200-240V 60A(50/60Hz) | ||
