DAEIL FABRICS WEFT STRAIGHTENER
- Compacted control circuit with powerful micro-computer and PLD. –
Easy operation by touch screen control – Minimized failure rate – Manual
bow roller available : A function not to operate for a bow roller by
detected wrinkle in fabric. – Compatible with future functions developed :
No change in hardware required by processing withinController a
program. - Skew Processing : A function to turn wefts in the specific state. – Good for
any defect caused by differences in both Stenter chain or for fabrics which
require for wefts to be turned. - Tension control : ±20% of speed change – To keep fixed tensile strength by
controlling bow roll according to speed. - TWILL function : Special used for twill fabrics (Good for comb’s teeth
pattern).
– For frequent malfunctions, it reduces an error rate by attaching a device
to distinguish cross angle with simultaneous detection of cross angle and
weft angle.
Dimension
