Canon IR C3120hadir dengan tampilan dan desain yang sederhana namun tetap berfungsi untuk memberikan produktivitas kerja dan keamanan kerja yang lebih baik ke alur kerja harian pengguna dengan mempermudah pengoperasian. Dengan teknologi warna V2, standar Wi-Fi dan Direct Access Point, nikmati hasil cetak warna berkualitas dengan koneksi mulus
- Duplex ADF
- Mobile Print Capabillity
- Direct Print dari USB ( PDF Format )
- Copy / Print Speed B/W & Color : 20 ppm
- Scan Speed B/W & Color : 55 ipm
- Maksimal Ukuran Kertas A3
- Maksimal Media Hingga 300 gsm
- Custom Size Up to SRA3
- Departement ID
- Standard Wireless LAN
- Full LCD Touchscreen Panel, including numeric panel
- Full Color ( C, M, Y, K )
| Main Unit | ||
| Machine Type | Colour Laser Multifunctional | |
| Core functions | Print, Copy, Scan, Send, Store and Optional Fax | |
| Processor | Canon Dual Custom Processor (Shared) | |
| Control Panel | 5 inch TFT LCD WVGA Colour Touch panel | |
| Memory | Standard: 2.0GB RAM | |
| Interface Connection | NETWORK | Standard: 1000Base-T / 100Base-TX / 10Base-T, Wireless LAN (IEEE 802.11 b/g/n); |
| Optional: NFC | ||
| OTHERS | Standard: USB 2.0 (Host) x2, USB 2.0 (Device) x1; | |
| Optional: Copy Control Interface | ||
| Paper Capacity (A4, 80/m²) | Standard: | 1,200 Sheets |
| Maximum: | 2,300 Sheets | |
| Paper Source (A4, 80/m²) | Standard: | Two 550-sheet paper cassettes 100-sheets Multi Purpose Tray |
| Optional: | Dual 550-sheet paper cassettes (CASSETTE FEEDING UNIT-AP1) | |
| Maximum: | 2,300 Sheets | |
| Paper output capacity (A4, 80/m²) | Standard: | 250 Sheets |
| With Inner Finisher: | 600 sheets *INNER FINISHER-K1 | |
| Finishing capabilities | Standard: | Collate, Group |
| With Inner Finisher: | Collate, Group, Offset, Staple, Staple-Free Staple, Staple-on-Demand | |
| Supported media sizes | Cassette 1: | Standard size: A4, B5, A5R |
| Envelopes: ISO-C5 | ||
| Custom Size: 139.7 x 182mm to 297 x 215.9mm | ||
| Cassette 2: | Standard size: A3, B4, A4, B5, A4R, A5R | |
| Envelopes: No.10 (COM10), Monarch, DL | ||
| Custom Size: 139.7 x 182mm to 304.8 x 457.2mm | ||
| Cassete 3/4 (CASSETTE FEEDING UNIT-AP1): | Standard size: A3, B4, A4, A4R, B5R, B5, A5R | |
| Custom Size: 139.7 x 182mm to 304.8 x 457.2mm | ||
| Multi-purpose tray: | Standard size: A3, B4, A4, A4R, B5R, B5, A5, A5R, SRA3 | |
| Custom size: 98.4 x 139.7mm to 320 x 457.2mm | ||
| Envelopes: No.10 (COM10), Monarch, ISO-C5, DL | ||
| Supported Media Weights | Cassette 1,2: | 52 to 220g/m² |
| Cassette Feeding Unit: | 52 to 220g/m² | |
| Multi-purpose tray: | Coated paper: 52 to 256g/m² | |
| Heavy Paper: 52 to 300g/m² | ||
| Duplex: | 52 to 220g/m² | |
| Warm-up Time | From Power On: | 30 Seconds or Less |
| From Sleep Mode: | 10 Seconds or Less | |
| Dimensions (W x D x H) | DADF-AV1: | 565 x 664 x 880mm |
| PLATEN COVER TYPE W: | 565 x 635 x 777mm | |
| Installation Space(W x D) | Basic: | 978 x 1,117mm (when attach with DADF-AV1 + Multi-purpose tray extension extended + Cassette open) 978 x 1,088mm (imageRUNNER C3120 + Multi-purpose tray extension extended + Cassette open) |
| Fully Configured: | 1,110 x 1,117mm （when attach with imageRUNNER C3120 + INNER FINISHER-K1 + Multi-purpose tray extension extended + Cassette open） | |
| Weight | Approx. 69.8kg including toner (when attach with DADF-AV1) | |
| Toner (Estimated Yield @ 5% Coverage) | Black: 36,000 Colour: 19,000 | |
| Drum Yield | 54,000 | |
| Print Specifications | ||
| Printing method | Colour Laser Beam Printing | |
| Print Speed (BW/CL) | 20ppm (A4), 15ppm (A3) | |
| Print Resolution | 600 x 600dpi, 1200 x 1200dpi | |
| Page description languages | UFR II （Standard）, PCL 6, Adobe PS3 (Option) | |
| Double Sided Printing | Automatic (Standard) | |
| Direct Print | Direct printing available from USB memory key Supported file types: TIFF, JPEG, PDF and XPS. | |
| Fonts | PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Barcode fonts* PS fonts: 136 Roman | |
| Operating System | UFRII: | Windows Vista / Server 2008 / Windows 7 / Server 2008 R2 / Windows 8 / Server 2012 / Windows 8.1 / Server 2012 R2 / Windows 10 / Server 2016, MAC OS X (10.7.5 or later), Linux |
| PCL: | Windows Vista / Server 2008 / Windows 7 / Server 2008 R2 / Windows 8 / Server 2012 / Windows 8.1 / Server 2012 R2 / Windows 10 / Server 2016 | |
| PS: | Windows Vista / Server 2008 / Windows 7 / Server 2008 R2 / Windows 8 / Server 2012 / Windows 8.1 / Server 2012 R2 / Windows 10 / Server 2016, MAC OS X (10.7.5 or later) | |
| PPD: | MAC OS 9.1 or later, MAC OS X (10.3.9 or later), Windows Vista / Windows 7 / Windows 8 / Windows10 | |
| Copy Specifications | ||
| Copy Speed (BW/CL) | 20ppm (A4), 15ppm (A3) | |
| First-Copy-Out Time (BW/CL) | Approx. 5.9 / 8.2 seconds or less | |
| Copy resolution | Reading: | 600 x 600dpi |
| Multiple Copies | Up to 999 copies | |
| Copy Exposure | Automatic or Manual (11 Levels) | |
| Magnification | 25 – 400% (1% Increments) | |
| Scan Specifications | ||
| Type | Colour Platen and Duplexing Automatic Document Feeder | |
| Supported media size/s | DADF-AV1: | A3, B4, A4R, A4, B5R, B5, A5R, A5, B6 |
| Pull Scan Specifications | Colour Network ScanGear2. For both TWAIN and WIA Supported OS: Windows Vista / 7 / 8 / 8.1 / 10 | |
| Scan Resolution | 300 x 300dpi, 600 x 600dpi | |
| Scan Method | Send, Scan to USB, Pull scanning | |
| Document Feeder Paper Capacity | DADF-AV1: | 100 Sheets (80g/m²) |
| Double sided scanning | 2-sided to 2-sided (Automatic) | |
| Send Specifications | ||
| Destination | E-mail / Internet FAX (SMTP), SMB, FTP, Super G3 FAX(Optional) | |
| Colour Mode | Auto Colour Select (Full Colour, Grayscale), Auto Colour Select (Full Colour/ Black-and-White) Full Colour, Grayscale, and Black-and-White | |
| Address Book | LDAP (5) / Local (300) / One-touch (281) | |
| Send resolution | 300 x 300dpi | |
| Communication protocol | File: FTP, SMB v3.0 | |
| E-mail / I-Fax: SMTP, POP3, I-Fax (Simple) | ||
| File Format | Standard: TIFF, JPEG, PDF(Compact, Searchable) | |
| Optional: PDF(Encrypted, Digital Signature) | ||
| Fax Specifications | ||
| Optional / Standard | Optional on all models | |
| Maximum Number of Connection Lines | 1 | |
| Modem Speed | Super G3: 33.6kbps G3: 14.4kbps | |
| Compression Method | MH, MR, MMR, JBIG | |
| Resolution | 400 x 400dpi, 200 x 400dpi, 200 x 200dpi, 200 x 100dpi | |
| Sending / Recording Size | A5* and A5R* to A3 *Sent as A4 | |
| FAX memory | Up to 512 pages | |
| Speed dials | Max. 281 | |
| Group dials | Max. 299 dials | |
| Security Specifications | ||
| Authentication | Standard: Department ID Authentication, uniFLOW connectivity | |
| Environmental Specifications | ||
| Operating Environment | Temperature: | 10 to 30°C (50 to 86°F) |
| Humidity: | 20 to 80% RH (no condensation) | |
| Power source | 220 – 240V (±10%), 50 / 60Hz (±2Hz), 4.0 Amp | |
| Power consumption | Maximum: | Approx. 1.5kW |
| Standby: | Approx. 33.6W* * Reference Value | |
| Sleep mode: | Approx. 2W (Wireless LAN power save mode:OFF), 1W (Wireless LAN power save mode:ON) | |
