ABG RTS Sheeter
Specification :
- Maximum Web Width : 330mm (13″) /430mm (17″)/ 530mm (21”)
- Maximum Speed : 10000 sheets/hour
- Maximum Unwind Roll Diameter : 700mm (27.5″)
- Standard Mandrel Diameter : 76mm (3”)
- Minimum/Maximum Sheet Length : 25mm (1″)/ 1000mm (39 ⅜”)
Features & Benefits :
- Accurate –100% of errors are detected, corrected and re-inspected.
- Easy-to-use –with intuitive, multilingual touchscreen control.
- Waste reducing –the RTS will stop automatically when the job is complete.
- Efficient operation –due to automated make ready control and a speed control function with automated speed limitation. Also included is a configurable missing registration mark window.
- High quality performance & control –high cutting accuracy combined with missing mark sensor and label detection
- Smooth operation –due to the unwind tension control system combined with the loop control supported by an ultrasonic sensor.
- Intersheet double cut –allows waste to be removed between sheets.
